| Length | 12,000 or 12,800 mm |
| Height | 4,327 mm |
| Width | 2,550 mm |
| Permitted GVW | 24,750 kg |
| Passenger capacity | Up to 100 |
| Number of seats | Up to 98 Lower deck 38 seats + 1 one wheelchair space Upper deck 60 seats |
| Seat types | Vogel Arondo seats Seats covered in moquette with plastic back Leather seat inserts as option Optional three-point seatbelts Chapman driver’s seat |
| Diesel engine | Volvo D8K, 6-cylinder, in-line diesel engine with common rail injection |
| Emission standard | Euro 6 Engine emission control uses SCR and EGR technology UK ZEMO low emission bus accreditation (LEB certified) |
| Max power output | 350 hp |
| Gearbox | ZF 6AP1620B 6-speed automatic with integral retarder |
| Fuel capacity | 350 l |
| Fuel tank | Aluminium fuel tank fitted under the staircase |
| Fuel filter | Right hand side (offside) Can be offered with Posi-Lock or Identic fast filling systems as an option |
24 volt negative earth system of multiplex design (BEA 3) 3 Bosch 150 amp alternators I-Start dual battery system Electronic monitoring of oil and coolant levels Electric engine cooling fans Engine oil top up system |
| Power steering | Electrically driven ZF Hydraulic power assisted steering The steering wheel position is adjustable for height and rake |
| Front axle | Volvo RFS-L |
| Rear axle | ZF AV133 |
| Tag axle | Fixed |
| Suspension | Electrically controlled air suspension Full squat option available for two door variant |
| Kneeling | Ferry lift and front axle kneeling |
| Wheels | Steel disc rim 8.25" x 22.5" |
| Tyres | 305/70 R22.5" |
| Brakes | Volvo disc brakes |
| Brake systems | Electronic Braking System (EBS5) – electronically controlled pneumatic system Anti-lock Braking System (ABS) Acceleration Slip Regulator (ASR) DBrake - door brake function, door brake interlock Brake blending Hill Start Aid Electronic Stability Control |
| Driver support | Brake temperature warning Lining wear indicator Automatic brake adjusters with wear compensation |
| Spacious driver’s environment with wide range of individual adjustments for outstanding ergonomics and comfort |
| ISRI Driver’s seat – Air suspension driver seat, fully adjustable, with lumber support, headrest, hands-free microphone, three-point seatbelt. |
LED interior and exterior lighting (excluding main beam) Ventura Inward Glider front entrance door with sensitive edge Lockable Hopper windows located throughout lower and upper deck White LED destination to front, side and rear Compak manual book leaf wheelchair ramp to front door Manually operated drivers sunblind Emergency exit door to the lower rear saloon on the offside Tinted side glass Wood effect flooring BMAC wireless bell pushes Two-year body warranty |
| Interior | Interior Next Stop announcers for bus service work PA and radio system Denso Air Conditioning with pre-heat Three point seat belts Seatbelt for drivers seat Two wheelchair spaces USB sockets Luggage racking |
| Body | Camera Mirror System (CMS) CCTV Wi-fi Induction loop Nearside and offside tree guard |
