Specifications for Volvo BZR Electric – CD

27,200 kg

8.200 kg

11.500 kg

7,500 kg

19,000 kg

ISRI driver's seat

integrated seat belt for driver

Steering wheel available in 450 mm or 500 mm

Steering wheel buttons for easy access

Volvo dashboard

Dashboard moves with the steering column in height

Integrated active safety notifications

View from reversing camera in monitor

Radio and phone handsfree kit integrated and controlled via steering wheel buttons

Full dynamic cluster with 12.3" digital display

Alcolock

Tachograph information in cluster

External temperature gauge

360° view camera

Rear-view camera with washer

Integrated radio with Bluetooth mobile connection

Automatic headlamp switch

Rain sensor

Charging information

Longer retarder stalk

Camera mirror system as standard

Volvo Dynamic Steering

Up to 57

Several materials and colour alternatives

LED lights

Emergency lighting system

Toilet in middle or rear

Wheelchair lift in the middle door

Refrigerator, several locations

Mini kitchen, several alternatives

Coffee machine, several locations

230 V sockets

USB-C sockets

WiFi

Multimedia displays

Modern design

Spacious and bright

Low noise level

Fire detection system

6-10 m³

Optional m³

Up to 1.9 m³

Driver and guide microphones

Foot-controlled public address system

Stereo radio with DAB

Bosch audio/video system

Two DIN units with radio and DVD

Driver’s monitor

USB

Navigation

HDMI

Roof mounted AC unit

Floor level heating with convectors and blowers

Driver AC as standard

Driver convector or blower

Electrical coolant heaters

Fuel operated heater (option)

Convectors or air blowers at doors

Separate climate zones for driver and passengers. For optimal climate and energy efficiency, the passenger area is controlled by a pre-defined temperature curve. The temperature in the driver's area is controlled automatically, but the driver can manually change the set temperature.

Pre-heating/cooling of the interior can be done when supported by the HVAC supplier.

Automatic pre-heating of windscreen

33,500

250 kw (CCS)

Charging inlets in several locations to suit your depot layout

600 V

5, 6, 7 or 8

450, 540, 630 or 720 kWh

Liquid-based thermal management system for active cooling and heating

Collision Warning with Emergency Brake

Forward Collision Warning

Cruise Control

Intelligent Speed Assist

Side Collision Avoidance Support

Front Short Range Assist

Lane Change Support

Lane Keeping Support

Driver Alert Support

Advanced Driver Distraction Warning

Tire Pressure Monitoring System

Emergency Stop Signal

I-Coaching

Volvo Dynamic Steering

Safety Zones

Electronic Stability Control

AVAS – Acoustic Vehicle Alerting System

Front Impact Protection

Knee Impact Protection

Front Underrun Protection System compliant with the R93 requirement

Rear Underrun and Impact Protection System compliant with the R58 requirement

Roll-over compliant with the R66 requirement

Flammability compliant with R118 requirement

Passenger two-point or three-point seat belts

Child seat

ESS and driveline monitoring

Active cooling and heating of batteries

Robust mechanical protection of batteries

Multilevel electrical protection

Automatic shutdown at detected risks

Hazardous Voltage Interlock Loop (HVIL)

Battery monitoring

Safety on cell and pack level (monitoring)

Insulation isolation resistance monitoring

Charging safety

Workshop safety

Mechanical protection

E-info session

Rescue sheet

Optional

LHD

Electric driven hydraulic steering

Optional

2

4

Electrically driven fans with speed control

No coolant filter

Thermal management system independent from climate system

Coolant level warning in instrumentcluster

Automated control of battery temperature with energy-efficient 600 V active cooling/heating system

Electric driveline and auxiliaries cooling circuit

Waste heat from the driveline circuit is used to heat the battery circuit through a heat exchanger

Volvo disc brakes

Electronic Braking System (EBS 5)

Anti-lock Braking System (ABS)

Anti Slip Regulation (ASR)

Brake blending

Hill Start Aid

Door brake

Brake Assist

Pneumatic system, easily accessible for external fill

Brake temperature warning

Automatic calibration after brake pad change

Poor brake performance warning

Lining wear sensing and analysis

Wear indicator on brake pads

2 x 12 V

2 x 170 Ah

Automatic shut off of main switch at low voltage level

The 24 V battery is monitored and charged from the traction batteries or grid when connected

Carrus Delta OY

Stainless steel on body structure and side panels

Anti-corrosion treatment of the underbody frame with conservation and silencing agent

Parts commonality between 9700 range coaches to lower the maintenance cost

Aerodynamics front geometry reducing vehicle air drag

Front and rear composite walls

Electrical heating system and UV protection in windscreen

Side window with light and dark tinted double glazing

Rear window with dark tinted double glazing

Driver window electrically operated, heated single glazing

Doors with double glazing

Bi-Xenon headlights with LED DRL

Auxiliary lights and fog lights as options

Brackets for ski-box or cycle carrier in the rear

Central locking of luggage compartment

Good access to service and maintenance locations

Pneumatic door system

1+1+0 or 1+0+1

Front door and middle or rear door

Outward swinging doors

315/80 R22.5″

8.25″ x 22.5″

27,200 kg

8.200 kg

11.500 kg

7,500 kg

19,000 kg

ISRI driver's seat

Integrated seat belt for driver

Steering wheel available in 450 mm or 500 mm

Steering wheel buttons for easy access

Volvo dashboard

Dashboard moves with the steering column in height

Integrated active safety notifications

View from reversing camera in monitor

Radio and phone handsfree kit integrated and controlled via steering wheel buttons

Full dynamic cluster with 12.3" digital display

Alcolock

Tachograph information in cluster

External temperature gauge

360° view camera

Rear-view camera with washer

Integrated radio with Bluetooth mobile connection

Automatic headlamp switch

Rain sensor

Charging information

Longer retarder stalk

Camera mirror system as standard

Volvo Dynamic Steering

Up to 61

Several materials and colour alternatives

LED lights

Emergency lighting system

Toilet in middle or rear

Wheelchair lift in the middle door

Refrigerator, several locations

Mini kitchen, several alternatives

Coffee machine, several locations

230 V sockets

USB-C sockets

WiFi

Multimedia displays

Modern design

Spacious and bright

Low noise level

Fire detection system

6–10 m³

Optional m³

Up to 1.9 m³

Driver and guide microphones

Foot-controlled public address system

Stereo radio with DAB

Bosch audio/video system

Two DIN units with radio and DVD

Driver’s monitor

USB

Navigation

HDMI

Roof mounted AC unit

Floor level heating with convectors and blowers

Driver AC as standard

Driver convector or blower

Electrical coolant heaters

Fuel operated heater (option)

Convectors or air blowers at doors

Separate climate zones for driver and passengers. For optimal climate and energy efficiency, the passenger area is controlled by a pre-defined temperature curve. The temperature in the driver's area is controlled automatically, but the driver can manually change the set temperature.

Pre-heating/cooling of the interior can be done when supported by the HVAC supplier.

Automatic pre-heating of windscreen

33,500

250 kW (CCS)

Charging inlets in several locations to suit your depot layout

600 V

5, 6, 7 or 8

450, 540, 630 or 720 kWh

Liquid-based thermal management system for active cooling and heating

Collision Warning with Emergency Brake

Forward Collision Warning

Cruise Control

Intelligent Speed Assist

Side Collision Avoidance Support

Front Short Range Assist

Lane Change Support

Lane Keeping Support

Driver Alert Support

Advanced Driver Distraction Warning

Tire Pressure Monitoring System

Emergency Stop Signal

I-Coaching

Volvo Dynamic Steering

Safety Zones

Electronic Stability Control

AVAS – Acoustic Vehicle Alerting System

Front Impact Protection

Knee Impact Protection

Front Underrun Protection System compliant with the R93 requirement

Rear Underrun and Impact Protection System compliant with the R58 requirement

Roll-over compliant with the R66 requirement

Flammability compliant with R118 requirement

Passenger two-point or three-point seat belts

Child seat

ESS and driveline monitoring

Active cooling and heating of batteries

Robust mechanical protection of batteries

Multilevel electrical protection

Automatic shutdown at detected risks

Hazardous Voltage Interlock Loop (HVIL)

Battery monitoring

Safety on cell and pack level (monitoring)

Insulation isolation resistance monitoring

Charging safety

Workshop safety

Mechanical protection

E-info session

Rescue sheet

Optional

LHD

Electric driven hydraulic steering

Optional

2

4

Electrically driven fans with speed control

No coolant filter

Thermal management system independent from climate system

Coolant level warning in instrument cluster

Automated control of battery temperature with energy-efficient 600 V active cooling/heating system

Electric driveline and auxiliaries cooling circuit

Waste heat from the driveline circuit is used to heat the battery circuit through a heat exchanger

Volvo disc brakes

Electronic Braking System (EBS 5)

Anti-lock Braking System (ABS)

Anti Slip Regulation (ASR)

Brake blending

Hill Start Aid

Door brake

Brake Assist

Pneumatic system, easily accessible for external fill

Brake temperature warning

Automatic calibration after brake padchange

Poor brake performance warning

Lining wear sensing and analysis

Wear indicator on brake pads

2 x 12 V

2 x 170 Ah

Automatic shut off of main switch at low voltage level

The 24 V battery is monitored and charged from the traction batteries or grid when connected

Carrus Delta OY

Stainless steel on body structure and side panels

Anti-corrosion treatment of the underbody frame with conservation and silencing agent

Parts commonality between 9700 range coaches to lower the maintenance cost

Aerodynamics front geometry reducing vehicle air drag

Front and rear composite walls

Electrical heating system and UV protection in windscreen

Side window with light and dark tinted double glazing

Rear window with dark tinted double glazing

Driver window electrically operated, heated single glazing

Doors with double glazing

Bi-Xenon headlights with LED DRL

Auxiliary lights and fog lights as options

Brackets for ski-box or cycle carrier in the rear

Central locking of luggage compartment

Good access to service and maintenance locations

Pneumatic door system

1+1+0 or 1+0+1

Front door and middle or rear door

Outward swinging doors

315/80 R22.5″

8.25″ x 22.5″

27,200 kg

8.200 kg

11.500 kg

7,500 kg

19,000 kg

ISRI driver's seat

Integrated seat belt for driver

Steering wheel available in 450 mm or 500 mm

Steering wheel buttons for easy access

Volvo dashboard

Dashboard moves with the steering column in height

Integrated active safety notifications

View from reversing camera in monitor

Radio and phone handsfree kit integrated and controlled via steering wheel buttons

Full dynamic cluster with 12.3" digital display

Alcolock

Tachograph information in cluster

External temperature gauge

360° view camera

Rear-view camera with washer

Integrated radio with Bluetooth mobile connection

Automatic headlamp switch

Rain sensor

Charging information

Longer retarder stalk

Camera mirror system as standard

Volvo Dynamic Steering

Up to 67

Several materials and colour alternatives

LED lights

Emergency lighting system

Toilet in middle or rear

Wheelchair lift in the middle door

Refrigerator, several locations

Mini kitchen, several alternatives

Coffee machine, several locations

230 V sockets

USB-C sockets

WiFi

Multimedia displays

Modern design

Spacious and bright

Low noise level

Fire detection system

6–10 m³

Optional m³

Up to 1.9 m³

Driver and guide microphones

Foot-controlled public address system

Stereo radio with DAB

Bosch audio/video system

Two DIN units with radio and DVD

Driver’s monitor

USB

Navigation

HDMI

Roof mounted AC unit

Floor level heating with convectors and blowers

Driver AC as standard

Driver convector or blower

Electrical coolant heaters

Fuel operated heater (option)

Convectors or air blowers at doors

Separate climate zones for driver and passengers. For optimal climate and energy efficiency, the passenger area is controlled by a pre-defined temperature curve. The temperature in the driver's area is controlled automatically, but the driver can manually change the set temperature.

Pre-heating/cooling of the interior can be done when supported by the HVAC supplier.

Automatic pre-heating of windscreen

33,500

250 kW (CCS)

Charging inlets in several locations to suit your depot layout

600 V

5, 6, 7 or 8

450, 540, 630 or 720 kWh

Liquid-based thermal management system for active cooling and heating

Collision Warning with Emergency Brake

Forward Collision Warning

Cruise Control

Intelligent Speed Assist

Side Collision Avoidance Support

Front Short Range Assist

Lane Change Support

Lane Keeping Support

Driver Alert Support

Advanced Driver Distraction Warning

Tire Pressure Monitoring System

Emergency Stop Signal

I-Coaching

Volvo Dynamic Steering

Safety Zones

Electronic Stability Control

AVAS – Acoustic Vehicle Alerting System

Front Impact Protection

Knee Impact Protection

Front Underrun Protection System compliant with the R93 requirement

Rear Underrun and Impact Protection System compliant with the R58 requirement

Roll-over compliant with the R66 requirement

Flammability compliant with R118 requirement

Passenger two-point or three-point seat belts

Child seat

ESS and driveline monitoring

Active cooling and heating of batteries

Robust mechanical protection of batteries

Multilevel electrical protection

Automatic shutdown at detected risks

Hazardous Voltage Interlock Loop (HVIL)

Battery monitoring

Safety on cell and pack level (monitoring)

Insulation isolation resistance monitoring

Charging safety

Workshop safety

Mechanical protection

E-info session

Rescue sheet

Optional

LHD

Electric driven hydraulic steering

Optional

2

4

Electrically driven fans with speed control

No coolant filter

Thermal management system independent from climate system

Coolant level warning in instrument cluster

Automated control of battery temperature with energy-efficient 600V active cooling/heating system

Electric driveline and auxiliaries cooling circuit

Waste heat from the driveline circuit is used to heat the battery circuit through a heat exchanger

Volvo disc brakes

Electronic Braking System (EBS 5)

Anti-lock Braking System (ABS)

Anti Slip Regulation (ASR)

Brake blending

Hill Start Aid

Door brake

Brake Assist

Pneumatic system, easily accessible for external fill

Brake temperature warning

Automatic calibration after brake pad change

Poor brake performance warning

Lining wear sensing and analysis

Wear indicator on brake pads

2 x 12 V

2 x 170 Ah

Automatic shut off of main switch at low voltage level

The 24 V battery is monitored and charged from the traction batteries or grid when connected

Carrus Delta OY

Stainless steel on body structure and side panels

Anti-corrosion treatment of the underbody frame with conservation and silencing agent

Parts commonality between 9700 range coaches to lower the maintenance cost

Aerodynamics front geometry reducing vehicle air drag

Front and rear composite walls

Electrical heating system and UV protection in windscreen

Side window with light and dark tinted double glazing

Rear window with dark tinted double glazing

Driver window electrically operated, heated single glazing

Doors with double glazing

Bi-Xenon headlights with LED DRL

Auxiliary lights and fog lights as options

Brackets for ski-box or cycle carrier in the rear

Central locking of luggage compartment

Good access to service and maintenance locations

Pneumatic door system

1+1+0 or 1+0+1

Front door and middle or rear door

Outward swinging doors

315/80 R22.5″

8.25″ x 22.5″
